MIL-PRF-39017G
APPENDIX A
*
A.3.2 Sample. The sample consisting of 294 sample units, 98 of the lowest, 98 of the highest, and 98
of the critical or nearest to critical value (see table A-I), and in each style and characteristic and
resistance tolerance for which qualification is sought, shall be submitted and subjected to the inspection
of table IX. If no critical value is specified, the samples will be equally divided between the highest and
lowest resistance values. In addition, 12 sample units, of any value or characteristic and 10 further
sample units of any resistance value shall be submitted and subjected to the tests of group II and group
VIII respectively, of table IX. When qualification for the RLR32 is desired, the above sample size shall be
divided equally between both styles. After qualification has been granted, no changes shall be made in
materials, design, or construction without prior notification to the qualifying activity.
*
TABLE A-I. Critical resistance value for qualification inspection. 1/
Style
Critical resistance value 2/
Megohms
.240
.240
.240
.316
1/ Maximum continuous working voltage shall be applied (see 3.1)
2/ The critical resistance value is the maximum standard resistance
value which will dissipate full wattage when the maximum
continuous working voltage is applied.
A.4. EXTENT OF QUALIFICATION
A.4.1 Extension of qualification. The resistance range included in the qualification of any one style and
tolerance shall be between any two adjacent resistance values which will pass the required qualification
inspection. The extent of qualification between product levels and resistance tolerances shall be as in
table A-II and table A-III.
TABLE A-II. Product levels.
Product level
Product
designator
level
R, P, M, C
S
P, M, C
R
M, C
P
M
C
44
