MIL-PRF-39005G

APPENDIX A

A.4.1.1 Additional samples for extension of tolerances qualification. Where qualification to a lower

resistance tolerance is desired (such as .02 percent, .01 percent), ten additional sample units each of the

highest value and lowest or 10 ohms, whichever is higher, in the lowest resistance tolerances for which

qualification is sought, shall be submitted and subjected to the inspection of group I, IA of table IX.

A.4.2 Extent of qualification by product level. The extension of qualification between failure rate

levels shall be as specified in table A-III.

TABLE A-III. Extent of qualification by product level.

Product level

Will qualify product level

R, P, M

P, M

C (non-ER)

A.4.3 Extent of qualification by terminal. The extension of qualification between terminal types

shall be as specified in table A-IV.

TABLE A-IV. Extent of qualification by terminal.

Terminal symbol

Will qualify symbol

U (with 60 additional U

submitted, see A.3.2)

L (with 70 additional L

submitted, see A.3.2)

A.5 SOLDER DIP (RETINNING) LEADS

A.5.1 Solder dip (retinning) leads. The manufacturer (or their authorized category B or category

C distributor) may solder dip/retin the leads of product supplied to this specification provided the

solder dip process (see A.5.2 of this appendix) or an equivalent process has been approved by the

qualifying activity.
