MIL-PRF-55182/9G
1.2.1.4 Resistance tolerance. The resistance tolerance is identified by a single letter in accordance with table IV.
TABLE IV. Resistance tolerance.
Symbol
Resistance
tolerance (percent)
±0.005
V
±0.01
T
±0.05
A
±0.1
B
±0.5
D
±1.0
F
1.2.1.5 Product level designator. The product level designator applicable to this specification shall be symbol C,
symbol M, symbol P, symbol R, symbol S, and symbol T.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those listed in the issue of the Department of Defense Index of Specifications and Standards (DoDISS) and
supplement thereto, cited in the solicitation (see 6.2).
SPECIFICATION
DEPARTMENT OF DEFENSE
MIL-PRF-55182 - Resistors, Fixed, Film, Nonestablished Reliability, Established Reliability, and Space
Level Reliability, General Specification for.
STANDARD
DEPARTMENT OF DEFENSE
MIL-STD-1276 - Leads for Electronic Component Parts.
(Unless otherwise indicated, copies of the above specifications, standards, and handbooks are available from the
Document Automation and Production Service, Building 4D, 700 Robbins Avenue, Philadelphia, PA 19111-5094.)
2.3 Order of precedence. In the event of a conflict between the text of this specification and the references cited
herein, the text of this document takes precedence. Nothing in this document, however, supersedes applicable laws
and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
MIL-PRF-55182.
3.2 Interface and physical dimensions. Resistors shall meet the interface and physical dimensions specified on
figure 1.
3
