INCH-POUND
MIL-PRF-55182/9G
26 September 2002
SUPERSEDING
MIL-PRF-55182/9F
9 June 1997
PERFORMANCE SPECIFICATION
RESISTORS, FIXED, FILM, NONESTABLISHED RELIABILITY,
*
ESTABLISHED RELIABILITY, AND SPACE LEVEL, STYLE RN*90 1/
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
*
1.1 Scope. This specification covers the associated requirements for style RN*90, nonestablished reliability,
established reliability, and space level, fixed, film, resistors. 1/
1.2 Classification.
1.2.1 Part or identifying number (PIN). The PIN is in the following form:
RN*90 1/
Y
562R00
B
M
|
|
|
|
|
_____|____
______|_____
_____|____
_____|_____
_____|_____
Style and
Characteristic
Resistance
Resistance
Product level
terminal type
(see 1.2.1.2)
(see 1.2.1.3)
tolerance
designator
(see 1.2.1.1)
(see 1.2.1.4)
(see 1.2.1.5)
1.2.1.1 Style and terminal type. Style and terminal type is identified by a three-letter symbol as indicated in table I
and a two digit number. The letters identify nonestablished reliability, established reliability, or space level, fixed, film,
resistors of a specified terminal type and the number "90" identifies the size and configuration of the resistor
applicable to this specification.
TABLE I. Style and terminal type.
Symbol
Terminal
Solderable/weldable (type C32, or C52 of MIL-STD-1276)
RNC
RNN 2/
Weldable (type N-2 of MIL-STD-1276)
2/ Type N terminals are not available for resistance values less than
500 ohms (see 6.3).
_______
1/ Third letter is variable, dependent upon lead material or capability.
