MIL-PRF-914/5B
TABLE II. Standard resistance values.
Resistance
R1
R2
Resistance
R1
R2
designator
(ohms)
(ohms)
designator
(ohms)
(ohms)
470
330
A010
130
82
A001
680
330
A011
200
20
A002
3,300
1,500
A012
210
130
A003
6,200
3,000
A013
260
160
A004
270
180
A014
240
180
A005
270
270
A015
390
180
A006
560
560
A016
270
220
A007
1,200
560
A017
330
220
A008
2,700
620
A018
390
330
A009
3.9 Resistance tolerance. Resistors are available in (B) ±0.1 percent, (D) ±0.5 percent, (F) ±1.0 percent, (G) ±2
percent, and (J) ±5 percent resistance tolerances.
3.10 Termination. Resistor terminations are available in following configurations.
Configuration
Termination
A
A, D, G
B
B, E, H
3.11 Marking. Due to the size limitations, this style resistor shall be marked with the following minimum
information, in the order as shown:
042K
-
Date code, characteristic
10K0
-
Coded resistance value
FAMJ
-
Tolerance, schematic, failure rate, JAN marking
3.12 Schematic. The schematic of the resistor network is identified by a single letter in accordance with
figure 2. The resistor element Rref is the reference resistor element used in determining the ratio accuracy (when
applicable).
3.13 Pure tin. The use of pure tin, as an underplate or final finish, is prohibited both internally and externally. Tin
content of resistor components and solder shall not exceed 97 percent, by mass. Tin shall be alloyed with a
minimum of 3 percent lead, by mass (see 6.4).
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-914.
4.2 "J" schematic tests. For tests on "J" schematic, the dc resistance measurements, resistance temperature
characteristic measurement, and short time overload application shall be made between each terminal and
applicable common terminal without compensation for the shunt circuits to determine the acceptability to section 3
requirements.
3
