MIL-PRF-914/3B
Configuration C
Inches
mm
Inches
mm
Ltr
Ltr
Min
Max
Min
Max
Min
Max
Min
Max
A
.015 .025
0.38
0.63
J
.292 .308
7.42 7.82
B
.015 .025
0.38
0.63
K
.015
---
0.38
---
C
.145 .155
3.68
3.94
L
.015 .025
0.38 0.63
D
.035 .045
0.89
1.14
M
.045 .055
1.14 1.38
E
.045 .055
1.14
1.38
N
.080 .090
2.03 2.29
F
---
.090
---
2.29
P
.022 .028
.056 0.71
G
---
.260
---
6.60
Q
.006 .022
0.15 0.56
H
.292 .308
7.42
7.82
R
.003 .010
0.08 0.25
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.008 (0.20 mm).
4. Adjacent corner pads may be rounded or diagonal cut to meet the .015 (0.38 mm) minimum requirement.
5. Pin number 1 locator shall be a dot adjacent to pin number 1.
6. The picturization of the styles above is given as representative of the envelope of the item. Slight deviations
from the outline shown, which are contained within the envelope and do not alter the functional aspect of the
device, are acceptable.
FIGURE 1. Leadless chip carrier - Continued.
6
