MIL-PRF-914/1A
TABLE II. Standard resistance values.
Resistance
R1
R2
Resistance
R1
R2
designator
(ohms)
(ohms)
designator
(ohms)
(ohms)
470
330
A010
130
82
A001
680
330
A011
200
120
A002
3.3 k
1.5 k
A012
210
130
A003
6.2 k
3k
A013
260
160
A004
270
180
A014
240
180
A005
270
270
A015
390
180
A006
560
560
A016
270
220
A007
1.2 k
560
A017
330
220
A008
2.7 k
620
A018
390
330
A009
5. PACKAGING
5.1 Packaging. For acquisition purposes, packaging requirements shall be as specified in the contract or
order (see 6.2). When actual packaging of material is to be performed by DoD personnel, these personnel
need to contact the responsible packaging activity to ascertain requisite packaging requirements.
Packaging requirements are maintained by the Inventory Control Point's packaging activity within the Military
Department or Defense Agency, or within the Military Department's System Command. Packaging data
retrieval is available from the managing Military Department's or Defense Agency's automated packaging
files, CD-ROM products, or by contacting the responsible packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not
mandatory.)
6.1 Intended use. Resistor networks are used in surface mount applications where space is a major
concern.
6.2 Acquisition requirements. Acquisition documents must specify the following:
a. Title, number, and date of the specification, and complete PIN.
b. Issue of DoDISS to be cited in the solicitation, and if required, the specific issue of individual
documents referenced (see 2.1).
c. Packaging requirements (see 5.1).
d. Allowable substitution.
6.3 Soldering. Extreme care should be taken when soldering these resistors. Prolonged exposure to
high temperatures can damage these devices.
6.4 PIN (see 1.2). PIN is a new term encompassing terms previously used in specifications such as part
number, type designator, identification, etc.
5
