MIL-PRF-83401-19 Resistor Network, Fixed, Film Style Rz190, 8-Pin SipThis specification covers the associated requirements for style RZ190, 8-pin single-in-line package \(SIP\) resistor network. This style is available in characteristic K and resistance tolerances of G. This specification has two product levels, a high reliability, 100 percent burn-in screened "M" part number and a nonburn-in screened part number "C". Designers are CAUTIONED on using these resistors in high power pulses applications \(see 6.4\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9

MIL-PRF-83401/19D

Inches

.004

0.10

.025

0.64

.006

0.15

.035

0.89

.009

0.23

.040

1.02

.010

0.25

.050

1.27

.012

0.30

.052

1.32

.015

0.38

.098

2.49

.019

0.48

.100

2.54

.020

0.51

.135

3.43

.023

0.58

.187

4.76

.783

19.89

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. Unless otherwise specified, tolerances are �.005 inch (0.13 mm).

4. The picturization of the styles above is given as representative of the envelope item. Slight deviations from

the outline shown, which are contained within the envelope and do not alter the functional aspects of the

device, are acceptable.

5. Terminal centerline to centerline measurements made at a point of emergence of the lead from the body.

6. Measurement made at the point of emergence of the lead from the body.

7. Pin 1 locator shall be a dot, notch, stripe, or numeral 1 adjacent to pin 1 in the shaded area, also, additional

markings may be placed on top edge where the bevel may be located.

8. If the standoffs are located on the body, a minimum of two standoffs are required as illustrated. As an

option, additional standoffs may be located on the body of the resistor network. If leads with standoffs are

used, standoffs on the body are not required.

FIGURE 2. Style RZ190 resistors - Continued.
