MIL-PRF-83401-19 Resistor Network, Fixed, Film Style Rz190, 8-Pin SipThis specification covers the associated requirements for style RZ190, 8-pin single-in-line package \(SIP\) resistor network. This style is available in characteristic K and resistance tolerances of G. This specification has two product levels, a high reliability, 100 percent burn-in screened "M" part number and a nonburn-in screened part number "C". Designers are CAUTIONED on using these resistors in high power pulses applications \(see 6.4\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9


.
MIL-PRF-83401/19D
TABLE I. Power rating.
Element power
Network power
PIN
rating (watts)
rating (watts)
M8340119KA001GX
C8340119KA001GX
0.10
0.60
M8340119KA002GX
C8340119KA002GX
0.10
0.60
M8340119KA003GX
C8340119KA003GX
0.10
0.60
M8340119KA004GX
C8340119KA004GX
0.10
0.60
M8340119KA005GX
C8340119KA005GX
0.10
0.60
M8340119KA006GX
C8340119KA006GX
0.10
0.60
M8340119KA007GX
C8340119KA007GX
0.10
0.50
M8340119KA008GX
C8340119KA008GX
0.10
0.50
M8340119KA009GX
C8340119KA009GX
0.10
0.50
M8340119KA010GX
C8340119KA010GX
0.10
0.40
M8340119KA011GX
C8340119KA011GX
0.10
0.60
M8340119KA012GX
C8340119KA012GX
0.10
0.60
3.4 Power conditioning. The power applied for power conditioning shall be 1.5 times rated power.
3.5 Voltage rating. The maximum continuous working voltage for each resistor shall not exceed 50 volts dc or ac
rms.
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-83401.
