MIL-PRF-39023/10C
4.1.3.1 Mounting. The resistor shall be mounted as specified in figure 4.
4.1.3.2 Dither. The dither test shall be specified in 4.7.21.2 of MIL-PRF-39023, with a dither life of 1.0 hour.
4.1.3.4 Mounting. The resistor shall be mounted as specified in figure 4.
4.1.4 Integrity of shaft.
4.1.4.1 Mounting. The resistor shall be mounted as specified in figure 4.
4.1.4.2 Pull force. A force of 2 pounds shall be applied along the axis of the operating shaft away from the body of
the resistor. The force shall be maintained for a minimum of 1 minute.
4.1.4.3 Examination after test. Resistors shall be examined for evidence of mechanical damage and tested for
electrical continuity.
4.1.5 Exclusions. The following tests are not applicable to this specification:
4.7.3 - 4.7.6, 4.7.9.3, 4.7.10, 4.7.15, and 4.7.24.
FIGURE 3. Measurement of static contact resistance.
5
