MIL-PRF-39015/1H
TABLE I. Nominal resistance value, and maximum resolution,
and maximum rated ac or dc working voltage.
Dash
Type
Nominal resistance
Maximum
Maximum rated ac or
number 4/
designation 1/
value (in ohms) 2/
resolution 3/
dc working voltage
Ohms
Volts
Percent
009
RTR12D-100-
10
2.2
2.7
010
RTR12D-200-
20
2.0
3.8
011
RTR12D-500-
50
1.3
6.1
001
RTR12D-101-
100
1.1
8.7
002
RTR12D-201-
200
0.9
12.3
003
RTR12D-501-
500
0.6
19.4
004
RTR12D-102-
1,000
0.5
27.5
005
RTR12D-202-
2,000
0.4
38.7
006
RTR12D-502-
5,000
0.3
61.3
007
RTR12D-103-
5/ 10,000
0.3
86.7
008
RTR12D-203-
0.3
122.0
6/ 20,000
1/ Complete type designation is for information only and will include additional symbols to
complete type designations.
2/ For Navy use, resistance values shall be based on the use of wire having no less than 0.001-
inch nominal (.0009 absolute) diameter.
3/ Maximum resolution shown are theoretical.
4/ Complete dash number will include symbols for terminal type and failure rate level.
5/ Value based on the use of wire having no less than 0.001-inch nominal (0.0009 absolute)
diameter.
6/ Value based on the use of wire having no less than 0.0008-inch nominal (0.00072 absolute)
diameter.
3.7 Weight. The maximum weight shall be 4.5 grams.
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-39015.
3
