MIL-PRF-29 Resistors, Fixed, Meter Multiplier, External \(High Voltage, Ferrule Terminal Type\)This specification covers the requirements for high-voltage, external, meter-multiplier, fixed resistors of the ferrule-terminal type for use with direct-current \(dc\) instruments drawing 1 milliampere at full-scale deflection. Designers are CAUTIONED on using these resistors in pulse applications \(see 6.5\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13


MIL-PRF-29C
Dimensions
E (dia)
Style
B
C
D
A
F
±.031
±.015 (dia)
±.015 (dia)
max.
Min.
Max.
MFA
8.687
9.781
.515 ±.015
1.140
MFB
4.187
5.281
MFD
13.5
16.5
1.390
.812
1.312
+0.010
MFE
20.5
23.5
1.156
1.5
-0.000
MFF
27.5
30.5
Resistor styles: MFA, MFB, MFD, MFE, and MFF.
Resistor styles MFC.
Dimensions
F (dia)
Style
B
C
E
A
D
G
H
±.031
±.015 (dia)
±.015 (dia)
max.
Min.
Max.
.515 ±.015
MFC
1.781
2.937
.812
.937
1.0
.687
1.078
.437
NOTES:
1.  All dimensions are in inches.
2.  These resistors should be supported by ferrule-terminals only.
FIGURE 1. Fixed Resistor.
3
