MIL-PRF-26/3E
TABLE III. Minimum and maximum nominal resistance values.
Resistance value (kohms)
Resistance
Resistor
Maximum
value (ohms)
style
Characteristic
Characteristic
Minimum
V
N
RW29
5.6
2.7
RW30 1/
2.7
---
RW31
6.8
3.3
RW32 1/
10
---
RW33
18
8.1
RW34 1/
30
---
0.10
RW35
43
20
RW36 1/
56
---
RW37
91
43
RW38
150
75
RW39 1/
200
---
180
81
RW47
1/ Not to be used for new design. For replacement purposes only.
3.5 Resistance tolerance. These resistors have a resistance range of 0.10 ohms to 200 kohms with the
following resistance tolerances:
a. Resistors of less than 1 ohm in resistance value shall have a tolerance of ±10 percent of the
nominal resistance value. If center-tapped, the resistance tolerance between tap and terminal
shall be ±10 percent.
b. Resistors of 1 ohm and over in resistance value shall have a tolerance of ±5 percent of the
nominal resistance value. If center-tapped, the resistance tolerance between tap and terminal
shall be ±10 percent.
3.6 Thermal shock. The resistors shall not change in resistance in excess of ±(2 percent +0.05 ohm).
3.7 Short-time overload. The resistors shall not change in resistance in excess of ±(2 percent +0.05
ohm).
3.8 High-temperature exposure. The resistors shall not change in resistance in excess of ±(2 percent
+0.05 ohm).
3.9 Moisture resistance. The resistors shall not change in resistance in excess of ±(2 percent +0.05
ohm).
3.10 Low-temperature storage. The resistors shall not change in resistance in excess of ±(2 percent
+0.05 ohm).
3.11 Life. The resistors shall not change in resistance in excess of ±(3 percent +0.05 ohm).
3.12 Solderability. Solderability is applicable to this specification
4
