MIL-PRF-26/3E
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this
document and MIL-PRF-26.
3.2 Interface and physical dimension. The resistor shall meet the interface and physical dimensions
specified on figure 1 and as specified herein.
3.3 Power rating. The power rating shall be as specified in table II, based on full load operation at an
ambient temperature of 25OC.
TABLE II. Power rating.
Power rating
in watts
Resistor
Characteristic
style
N
V
RW29
11
11
RW30
---
11
RW31
14
14
RW32
---
17
RW33 1/
26
26
RW34 1/
---
43
RW35 1/
55
55
RW36 1/
---
78
RW37 1/
113
113
RW38 1/
159
159
RW39 1/
---
240
RW47 1/
210
210
1/ The power rating of center-tapped
resistors shall be 90 percent of those
shown.
3.4 Resistance. The minimum and maximum nominal resistance values shall be as specified in
table III.
3.4.1 Standard resistance values. For standard resistance values see MIL-PRF-26.
3
