MIL-PRF-22097/4F
3.3 Power rating. The power rating shall be .5 watt for characteristic C and F.
3.4 Terminals. Characteristic C and characteristic F are available with L-type, P-type, W-type, and X-type
terminals.
3.5 Nominal resistance value and maximum rated ac or dc working voltage. Nominal resistance values and
maximum rated ac or dc working voltages shall be as specified in table I.
TABLE I. Nominal resistance value and maximum rated ac or dc working voltage.
Maximum rated ac or dc
Maximum rated ac or dc
Nominal
Nominal
working voltage per
working voltage per
resistance value
resistance value
characteristic C and
characteristic C and
(Ohms)
(Ohms)
characteristic F
characteristic F
(Volts)
(Volts)
10
2.23
10,000
70.7
20
3.1
20,000
100
50
5.0
25,000
111
100
7.0
50,000
158
200
10.0
100,000
223
500
15.8
200,000
300
1,000
22.3
250,000
300
2,000
31.6
500,000
300
5,000
50.0
1,000,000
300
3.6 Actual effective electrical travel. Actual effective electrical travel shall be 15 turns minimum, and 30 turns
maximum.
3.7 Operating torque. Operating torque shall be a maximum of 5 ounce-inches.
3.8 Pure tin. The use of pure tin, as an underplate or final finish, is prohibited both internally and externally. Tin
content of resistor components and solder shall not exceed 97 percent, by mass. Tin shall be alloyed with a
minimum of 3 percent lead, by mass (see 6.4).
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-22097, and as
specified herein.
4.2 Dielectric withstanding voltage. The magnitude of test voltage shall be 900 volts at atmospheric pressure, and
350 volts at reduced barometric pressure.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military Department's
or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible packaging
activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Intended use. The notes specified in MIL-PRF-22097 are applicable to this specification.
