MIL-PRF-22/9D
TABLE III. Style of shaft and type of mounting.
.25 inch diameter shaft
Symbol
Style of shaft
Standard bushing
Locking bushing
F
Flatted
X
S
Slotted
X
T
Flatted
X
U
Slotted
X
TABLE IV. Length of operating shaft.
Standard length of shaft measured from mounting surface of resistor
Flatted
Slotted
0.25 inch diameter shaft in inches (0.0468)
Symbol
Standard
Locking
Standard
Locking
bushing
bushing
bushing
bushing
A
0.500
B
0.625
D
0.875
0.875
G
1.250
1.250
H
1.500
1.500
J
2.000
2.000
2.500
K
2.500 1/
N
4.000
R
6.000
1/
This shaft shall be flatted to within 0.156 inch of the mounting bushing.
4. VERIFICATION
4.1 Sampling and inspection. Sampling for delivery shall be in accordance with MIL-PRF-22.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point s packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military Department s
or Defense Agency s automated packaging files, CD-ROM products, or by contacting the responsible packaging
activity.
6. NOTES
(This section contains information of general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Notes. The notes specified in MIL-PRF-22 will be applicable to this specification.
