MIL-PRF-22/9D
TABLE I. Style RP30.
Nominal total
Type designator
Maximum current
PIN 1/
resistance
1/
(amperes) 2/
(ohms)
M22/09-0001---
RP30---2R0KK
2.0
8.66
M22/09-0002---
RP30---2R5KK
2.5
7.75
M22/09-0003---
RP30---3R0KK
3.0
7.07
M22/09-0004---
RP30---4R0KK
4.0
6.12
M22/09-0005---
RP30---5R0KK
5.0
5.48
M22/09-0006---
RP30---6R0KK
6.0
5.00
M22/09-0007---
RP30---8R0KK
8.0
4.33
M22/09-0008---
RP30---100KK
10
3.87
M22/09-0009---
RP30---120KK
12
3.54
M22/09-0010---
RP30---150KK
15
3.16
M22/09-0011---
RP30---250KK
25
2.45
M22/09-0012---
RP30---350KK
35
2.07
M22/09-0013---
RP30---500KK
50
1.73
M22/09-0014---
RP30---750KK
75
1.41
M22/09-0015---
RP30---101KK
100
1.22
M22/09-0016---
RP30---151KK
150
1.00
M22/09-0017---
RP30---201KK
200
0.87
M22/09-0018---
RP30---251KK
250
0.77
M22/09-0019---
RP30---351KK
350
0.66
M22/09-0020---
RP30---501KK
500
0.55
M22/09-0021---
RP30---751KK
750
0.45
M22/09-0022---
RP30---102KK
1,000
0.39
M22/09-0023---
RP30---152KK
1,500
0.32
M22/09-0024---
RP30---252KK
2,500
0.25
M22/09-0025---
RP30---352KK
3,500
0.21
M22/09-0026---
RP30---502KK
5,000
0.17
M22/09-0027---
RP30---802KK
8,000
0.14
M22/09-0028---
RP30---103KK
10,000
0.12
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
4
