MIL-PRF-22/7D
TABLE I. Style RP20.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance (ohms)
(amperes) 2/
M22/07-0001---
RP20---2R0KK
2.0
6.12
M22/07-0002---
RP20---2R5KK
2.5
5.50
M22/07-0003---
RP20---3R0KK
3.0
5.00
M22/07-0004---
RP20---4R0KK
4.0
4.34
M22/07-0005---
RP20---5R0KK
5.0
3.87
M22/07-0006---
RP20---6R0KK
6.0
3.54
M22/07-0007---
RP20---8R0KK
8.0
3.06
M22/07-0008---
RP20---100KK
10
2.74
M22/07-0009---
RP20---120KK
12
2.50
M22/07-0010---
RP20---150KK
15
2.24
M22/07-0011---
RP20---250KK
25
1.73
M22/07-0012---
RP20---350KK
35
1.46
M22/07-0013---
RP20---500KK
50
1.22
M22/07-0014---
RP20---750KK
75
1.00
M22/07-0015---
RP20---101KK
100
0.87
M22/07-0016---
RP20---151KK
150
0.71
M22/07-0017---
RP20---201KK
200
0.61
M22/07-0018---
RP20---251KK
250
0.55
M22/07-0019---
RP20---351KK
350
0.46
M22/07-0020---
RP20---501KK
500
0.39
M22/07-0021---
RP20---751KK
750
0.32
M22/07-0022---
RP20---102KK
1,000
0.27
M22/07-0023---
RP20---152KK
1,500
0.22
M22/07-0024---
RP20---252KK
2,500
0.17
M22/07-0025---
RP20---352KK
3,500
0.15
M22/07-0026---
RP20---502KK
5,000
0.12
M22/07-0027---
RP20---802KK
8,000
0.10
M22/07-0028---
RP20---103KK
10,000
0.09
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
table III and length of operating shaft from table IV. (see 1.2 for example
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
.25 inch diameter shaft
Symbol
Style of shaft
Standard bushing
Locking bushing
F
Flatted
X
S
Slotted
X
T
Flatted
X
U
Slotted
X
4
