MIL-PRF-94/6E
3.3 Nominal total resistance and rated continuous working voltages. The nominal total resistance and rated
continuous working voltage (RCWV) shall be as specified in table III. These voltage ratings are based on full power
dissipation in the specified section. For other combinations of power ratings listed in 3.5, the applicable working
voltage should be calculated from the following formula:
E = PR
Where
E = Rated dc or root mean square (rms) continuous working voltage.
P = Power rating.
R = Nominal total resistance.
TABLE III. Nominal total resistance and rated continuous working voltage.
RCWV 1/
Resistance characteristic combination
Nominal total
Resistance
A
C
G
H
(in ohms)
Panel
Rear
Panel
Rear
Panel
Rear
Panel
Rear
section
section
section
section
section
section
section
section
50
10
10
9
9
100
14
14
9
13
10
10
13
9
150
17
17
11
15
12
12
15
11
200
20
20
18
18
250
22
22
14
20
16
16
20
14
350
26
26
17
24
18
18
24
17
500
32
32
20
28
23
23
28
20
750
39
39
24
35
28
28
35
24
1,000
45
45
28
40
32
32
40
28
1,500
55
55
35
49
39
39
49
35
40
2,000
63.3
63
40
57
45
45
57
45
2,500
71
71
45
63
50
50
63
53
3,500
84
84
53
75
60
60
75
63
5,000
100
100
63
89
71
71
89
77
7,500
122
122
77
110
87
87
110
89
10,000
141
141
89
126
100
100
126
109
15,000
173
173
109
155
123
123
155
126
20,000
200
200
126
179
141
141
179
200
141
25,000
224
224
141
200
160
160
237
167
35,000
264
264
167
237
187
187
283
200
50,000
316
316
200
283
224
224
346
245
75,000
387
387
245
346
249
249
400
283
0.10M
445
445
283
400
316
316
490
346
0.15M
500
500
346
490
350
350
500
350
0.20M
500
500
350
500
350
350
500
350
0.25M
500
500
350
500
350
350
500
350
0.35M
500
500
350
500
350
350
500
350
0.50M
500
500
350
500
350
350
500
350
0.75M
500
500
350
500
350
350
500
350
1.00M
500
500
350
500
350
350
500
350
1.50M
500
500
350
500
350
350
500
350
2.00M
500
500
350
500
350
350
500
350
2.50M
500
500
350
500
350
350
500
350
3.50M
500
500
350
500
350
350
500
350
5.00M
500
500
350
500
350
350
1/ Rated for continuous working voltage at 70OC. These are maximum values that would apply
only when the other section has zero wattage dissipated.
