MIL-PRF-83401/22B
Inches
mm
Inches
mm
.025
0.64
.004
0.10
.035
0.89
.006
0.15
.040
1.02
.009
0.23
.050
1.27
.010
0.25
.052
1.32
.012
0.30
.098
2.49
.015
0.38
.100
2.54
.019
0.48
.135
3.43
.020
0.51
.187
4.76
.023
0.58
.783
19.89
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.005 inch (0.13 mm).
4. The picturization of the style above is given as representative of the envelope item. Slight deviations
from the outline shown, which are contained within the envelope and do not alter the functional aspects of
the device, are acceptable.
5. Terminal centerline to centerline measurements made at point of emergence of the lead from the body.
6. Measurement made at point of emergence of the lead from the body.
7. Pin 1 locator shall be a dot, notch, stripe, or numeral 1 adjacent to pin no. 1, in the shaded area, also,
additional marking may be placed on the top edge where the bevel may be located.
8. If the standoffs are located on the body, a minimum of two standoffs are required as illustrated. As an
option, additional standoffs may be located on the body of the resistor network. If leads with standoffs are
used, standoffs on the body are not required.
FIGURE 1. Style RZ220 resistors - Continued.
4.2 H schematic tests. For the tests on H schematic, the dc resistance measurements, resistance temperature
characteristic measurement, and short time overload power application shall be made between each terminal and the
applicable common terminal without compensation for the shunt circuits. The pin to pin dc resistance measurements
shall be used directly to determine the acceptability to section 3 requirements.
5. PACKAGING
*
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activities within the Military Service or Defense Agency, or
within the military service's system commands. Packaging data retrieval is available from the managing Military
Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
