INCH-POUND
MIL-PRF-83401/22B
5 May 2006
SUPERSEDING
MIL-PRF-83401/22A
18 March 1996
PERFORMANCE SPECIFICATION SHEET
RESISTOR NETWORK, FIXED, FILM,
STYLE RZ220, 8 PIN SIP
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the associated requirements for style RZ220, 8 pin single-in-line package
(SIP) resistor networks. This style is available in all characteristics and all resistance tolerances. This specification
has two product levels, a high reliability, 100 percent burn-in screened "M" part number level and nonburn-in
screened part number "C".
1.2 Part of Identifying Number (PIN). Resistor networks covered by this specification are identified by a PIN which
will consist of the basic number of this specification and a coded number. The PIN is in the following form:
100 percent burn-in screened network ("M" part number)
M8340122
H1002FC
|
_
|______
Associated specification number
Coded number
Nonburn-in screened network ("C" part number)
C8340122
H1002FC
|
_
|______
Associated specification number
Coded number
The coded number is derived in accordance with MIL-PRF-83401.
Comments, suggestions, or questions on this document should be addressed to: Defense Supply Center,
Columbus ATTN: DSCC-VAT, Post Office Box 3990, Columbus, Ohio 43218-3990, or emailed to
resistor@dla.mil. Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online database at https://assist.daps.dla.mil.
AMSC N/A
FSC 5905
