MIL-PRF-83401-18 Resistor Network, Fixed, Film Style Rz180, 6 Pin SipThis specification covers the associated requirements for style RZ180, 6 pin single in-line package \(SIP\) resistor network. This style is available in characteristic K and resistance tolerance G. This specification has two product levels, a high reliability, 100 percent burn-in screened "M" part number and a nonburn-in screened part number "C". Designers are CAUTIONED on using these resistors in high power pulses applications \(see 6.4\).

Pages 1 - 2 - 3 - 4 - 5

MIL-PRF-83401/18C

Inches

.004

0.10

.025

0.64

.006

0.15

.035

0.89

.009

0.23

.040

1.02

.010

0.25

.050

1.27

.012

0.30

.052

1.32

.015

0.38

.098

2.49

.019

0.48

.100

2.54

.020

0.51

.135

3.43

.023

0.58

.187

4.75

.583

14.81

NOTES:

1. Dimensions are in inches.

2. Metric equivalents are given for general information only.

3. Unless otherwise specified, tolerances are �.005 inch (0.13 mm).

4. The picturization of the styles above is given as representative of the envelope item. Slight deviations from

the outline shown, which are contained within the envelope and do not alter the functional aspects of the

device, are acceptable.

5. Terminal centerline to centerline measurements made at point of emergence of the lead from the body.

6. Measurements made at the point of emergence of the lead of the body.

7. Pin 1 locator shall be a dot, notch, stripe, or numeral 1 adjacent to pin no. 1, in the shaded area; also,

additional marking may be placed on top edge where the bevel may be located.

8. If the standoffs are located on the body, a minimum of two standoffs are required as illustrated. As an

option, additional standoffs may be located on the body of the resistor network. If leads with standoffs are

used, standoffs on the body are not required.

FIGURE 1. Style RZ180 resistors - Continued.

3. REQUIREMENTS

3.1 Associated specifications. The individual item requirements shall be in accordance with MIL-PRF-83401, as

specified herein.

3.2 Interface and physical dimensions. The resistor shall meet the interface and physical dimensions specified on

figure 1.

3.3 Power rating (70�C). The power ratings shall be in accordance with table I.

Element power

Network power

rating (watts)

M8340118KA001GX

C8340118KA001GX

0.10

0.40

M8340118KA002GX

C8340118KA002GX

0.10

0.50

3.4 Power conditioning. The power applied for power conditioning shall be 1.5 times rated power.

3.5 Voltage rating. The maximum continuous working voltage for each resistor shall not exceed 50 volts dc or ac

rms.
