INCH-POUND
MIL-PRF-83401/18C
5 May 2006
SUPERSEDING
MIL-PRF-83401/18B(USAF)
18 March 1996
PERFORMANCE SPECIFICATION SHEET
RESISTOR NETWORK, FIXED, FILM
STYLE RZ180, 6 PIN SIP
This specification is approved for use by the Department
of the Air Force and is available for use by all Departments
and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification covers the associated requirements for style RZ180, 6 pin single in-line package
(SIP) resistor network. This style is available in characteristic K and resistance tolerance G. This specification has
two product levels, a high reliability, 100 percent burn-in screened "M" part number and a nonburn-in screened part
number "C".
1.2 Part or Identifying Number (PIN). Resistor networks covered by this specification are identified by a PIN which
will consist of the basic number of this specification and a coded number. The PIN is in the following form:
100 percent burn-in screened network ("M" part number)
M8340118
KA001GX
|
_
|______
Associated specification number
Coded number
Nonburn-in screened network ("C" part number)
C8340118
KA001GX
|
_
|______
Associated specification number
Coded number
The coded number is derived in accordance with MIL-PRF-83401.
