MIL-PRF-55342-1 Resistors, Chip, Fixed, Film, Nonestablished Reliability, Established Reliability, Space Level, Style Rm0502This specification covers the requirements for style RM0502, fixed, film, chip, nonestablished reliability, established reliability, and space level resistors. This style is available in characteristic H, characteristic E, characteristic K, characteristic L, and characteristic M, resistance tolerances .1 percent, .25 percent, .5 percent, 1 percent, 2 percent, 5 percent, and 10 percent, and all termination materials. Designers are CAUTIONED on using these resistors in high power pulses applications \(see 6.5\).

Pages 1 - 2 - 3 - 4 - 5

INCH-POUND

MIL-PRF-55342/1J

31 October 2003

SUPERSEDING

MIL-PRF-55342/1H

3 July 1997

PERFORMANCE SPECIFICATION

RESISTORS, CHIP, FIXED, FILM,

NONESTABLISHED RELIABILITY, ESTABLISHED RELIABILITY, SPACE LEVEL,

STYLE RM0502

This specification is approved for use by all Departments

and Agencies of the Department of Defense.

1. SCOPE

1.1 Scope. This specification covers the requirements for style RM0502, fixed, film, chip,

nonestablished reliability, established reliability, and space level resistors. This style is available in

characteristic H, characteristic E, characteristic K, and characteristic M, resistance tolerances .1 percent,

1 percent, 2 percent, 5 percent, and 10 percent, and all termination materials.

1.2 Part or Identifying Number (PIN). Chip resistors covered by this specification must be identified by

a PIN which must consist of the basic number of this specification and a coded dash number. The PIN

must be in the following form:

M55342H01

B1E00M

Coded dash

Performance

specification

number

The coded dash number is derived in accordance with MIL-PRF-55342.

2. APPLICABLE DOCUMENTS

2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.

This section does not include documents cited in other sections of this specification or recommended for

additional information or as examples. While every effort has been made to ensure the completeness of

this list, document users are cautioned that they must meet all specified requirements of documents cited

in sections 3 and 4 of this specification, whether or not they are listed.

Comments, suggestions, or questions on this document should be addressed to: US Army Communications -

Electronics Command and Fort Monmouth, ATTN: AMSEL-LC-LEO-E-EP, Fort Monmouth, NJ 07703-5023 or

emailed to Jeffery.Carver@mail1.monmouth.army.mil. Since contact information can change, you may want to

verify the currency of this address information using the ASSIST Online database at www.dodssp.daps.mil.

AMSC N/A

FSC 5905

DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
