MIL-PRF-55182/5M
3.3 Power rating. The power rating shall be 0.250 watt (see 6.3).
3.4 Voltage rating. The continuous working voltage shall not exceed 300 volts.
3.5 Resistance. Minimum and maximum resistance values shall be as specified in table I.
TABLE I. Minimum and maximum resistance values.
Minimum resistance
Maximum resistance
Characteristic
Ohms
Characteristic
Megohms
8.06
H
1.0
H 1/
8.06
J
10.0
J
8.06
K
1.0
K 1/
4.99
C
10.0
C
4.99
E
10.0
E
1/ For resistance tolerance D and resistance tolerance F only.
For resistance tolerance B, the minimum resistance value
shall be 10.0 ohms.
3.6 Voltage coefficient (applicable to resistors of 1,000 ohms and above). The voltage coefficient shall not exceed
±0.005 percent per volt.
4. VERIFICATION
4.1 Verification. Verification shall be in accordance with MIL-PRF-55182.
5. PACKAGING
5.1 Packaging requirements. For acquisition purposes, the packaging requirements shall be as specified in the
contract or order. When actual packaging of material is to be performed by DoD personnel, these personnel need to
contact the responsible packaging activity to ascertain requisite packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Department or Defense Agency, or within
the Military Department's System Command. Packaging data retrieval is available from the managing Military
Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature which may be helpful, but is not mandatory.)
6.1 Notes. The notes specified in MIL-PRF-55182 are applicable to this specification.
6.2 Acquisition requirements. Acquisition documents must specify the following:
a. Title, number, and date of the specification.
b. Issue of DoDISS to be cited in the solicitation, and if required, the specific issue of individual documents
referenced (see 2.2.1).
*
c. Packaging requirements (see 5.1). (i.e. Electrostatic discharge (ESD) sensitive packaging).
3
