MIL-PRF-39035/1E
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-39035.
4.2 Visual and mechanical inspection. Visual and mechanical inspection shall be in accordance with
4.3 Dielectric withstanding voltage. The magnitude of test voltage shall be 900 volts for all characteristics at
atmospheric pressure, and 350 volts for all characteristics at reduced barometric pressure.
TABLE I. Nominal resistance value and maximum rated ac or dc working voltage.
Maximum rated ac or
Maximum rated ac or
Nominal resistance
Nominal resistance
dc working voltage per
dc working voltage per
value
value
characteristics
characteristics
(in Ohms)
(in Ohms)
C, F, and H
C, F, and H
10
2.73
20,000
122
20
3.8
25,000
136
50
6.1
50,000
194
100
8.7
200
12.3
megohms
500
19.4
0.10
274
1,000
27.4
0.20
300
2,000
38.7
0.25
300
5,000
61.3
0.50
300
10,000
86.7
1.00
300
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military
Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible
packaging activity
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but not mandatory.)
6.1 Intended use. The notes specified in MIL-PRF-39035 are applicable to this specification.
6.2 Acquisition requirements. Acquisition documents must specify the following:
Title, number, and date of this specification, and the complete PIN (see 1.2).
a.
b.
If not otherwise specified (see 2.1), the versions of the individual documents referenced will be those in
effect on the date of release of the solicitation.
c.
Packaging instructions (see 5.1).
4
