MIL-PRF-39005/11C
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
*
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-PRF-39005 - Resistors, Fixed, Wire-Wound (Accurate), Nonestablished Reliability and
Established Reliability, General Specification for.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or from the
*
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-
5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the event of a conflict between the text
*
of this document and the references cited herein (except for related specification sheets), the text of this
document takes precedence. Nothing in this document, however, supersedes applicable laws and
regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this
document and MIL-PRF-39005.
3.2 Interface and physical dimensions. Resistors shall meet the interface and physical dimensions
specified on figure 1.
3.3 Minimum resistance value and applicable tolerance. Minimum resistance values and applicable
tolerances are as follows:
Minimum resistance
Resistance tolerance
(ohms) 1/
(percent)
T (±0.01)
1000
Q (±0.02) and A (±0.05)
100
B (±0.10) and F (±1.0)
10
1/ Minimum resistance values are available for both styles RBR80
and RBR81, but it is preferred that style RBR81 be limited in use to
resistance values exceeding 0.120 megohms.
3.4 Maximum resistance value. Maximum resistance values shall be as follows:
Resistor style
Maximum resistance 1/
(megohms)
RBR80
0.120
RBR81
0.250
1/ Based on use of .0006-inch or larger diameter wire.
2
