MIL-PRF-39005/10B
6.2 Acquisition requirements. Acquisition documents must specify the following:
a. Title, number, and date of the specification.
b. Issue of DoDISS to be cited in the solicitation, and if required, the specific issue of individual documents
referenced (see 2.1.1).
c. Packaging requirements (see 5.1).
Dimension
Inches
Millimeters
A
0.812 +0.020
20.62 +0.51
-0.032
-0.81
B
0.312 0.015
7.92 0.38
C
1.500 min
38.10 min
D
0.032 0.002
0.81 0.05
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Dimension A is 'clean lead to clean lead'.
FIGURE 1. Style RBR76 resistor.
3
