MIL-PRF-26/4F
3.2 Interface and physical dimension. The resistor shall meet the interface and physical dimensions
specified on figure 1 and as specified herein.
3.3 Power rating. The power rating shall be as specified in table II, based on full load operation at an
ambient temperature of 25OC.
TABLE II. Power rating.
Resistor
Power rating in watts
style
Characteristic V
RW55
7
RW56
14
RW67
6.5
RW68
11
RW69
3
3.4. Resistance. The minimum and maximum nominal resistance values shall be as specified in
table III.
3.4.1 Standard resistance values. For standard resistance values see MIL-PRF-26.
TABLE III. Minimum and maximum nominal resistance values.
Resistance value (kohms)
Resistor
style
Minimum
Maximum
RW55
5.1
RW56
9.1
0.10
RW67
8.2
RW68
20.0
RW69
2.0
3.5 Resistance tolerance. Resistors of less than 1 ohm in resistance value shall have a tolerance of
±10 percent of the nominal resistance value. Resistors of 1 ohm and over in resistance value shall have a
tolerance of ±5 percent of the nominal resistance value.
3
