MIL-PRF-26/4F
Minimum and maximum resistance values are as specified herein. The standard values for every decade
should follow the sequence demonstrated for the "10 to 100" decade in accordance with MIL-PRF-26.
TABLE I. Characteristic.
Minimum insulation
Maximum continuous
Resistance temperature characteristic
Symbol
resistance at end of
(ppm/OC)
operation temperature 1/
moisture resistance
0 ±260 >20 ohms
0 ±400 >10 ohms to <20 ohms
350OC
V 2/
100 Megohms
0 +400, -200 >1 ohm to <10 ohms
0 +500, -100 >0.499 ohm to <1 ohm
0 +650, -100 >0.1 ohm to < 0.499 ohm
1/ This temperature is also the maximum permissible hot-spot surface temperature.
2/ Inductive wirewound.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
this list, document users are cautioned that they must meet all specified requirements documents cited in
sections 3 and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATION
-
Resistors, Fixed, Wire Wound (Power Type), General Specification for.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or
https://assist.daps.dla.mil or from the Standardization Document Order Desk, 700 Robbins Avenue,
Building 4D, Philadelphia, PA 19111-5094).
2.3 Order of precedence. In the event of a conflict between the text of this document and the
references cited herein, the text of this document takes precedence. Nothing in this document, however,
supersedes applicable laws and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this
document and MIL-PRF-26.
