MIL-PRF-22684-8 Resistors, Fixed, Film, Insulated, Style Rl42....TxThis specification covers the associated requirements for insulated, film, fixed resistors of 2-percent and 5-percent resistance tolerance. These resistors are capable of full-load operation at an ambient temperature of 70 degrees C and have a resistance-temperature characteristic of +200 parts per million per degree Celsius \(ppm/degrees C\). Designers are CAUTIONED on using these resistors in high power pulse applications \(see 6.3\)

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8

MIL-PRF-22684/8C

2.2 Government documents.

2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and

handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the

issues of these documents are those listed in the issue of the Department of Defense Index of

Specifications and Standards (DoDISS) and supplement thereto, cited in the solicitation (see 6.2).

SPECIFICATION

DEPARTMENT OF DEFENSE

MIL-PRF-22684 - Resistors, Fixed, Film (Insulated), General Specification.

STANDARDS

DEPARTMENT OF DEFENSE

MIL-STD-202 - Test Method Standard, Electronic and Electrical Component Parts.

MIL-STD-1285 - Marking of Electrical and Electronic Parts.

(Unless otherwise indicated, copies of the above specifications, standards, and handbooks are available

from the Defense Automated Printing Service, Building 4D (DPM-DoDSSP), 700 Robbins Avenue,

Philadelphia, PA 19111-5094.)

2.3 Order of precedence. In the event of a conflict between the text of this document and the

references cited herein (except for related association specification, specification sheets, or MS

standards), the text of this document takes precedence. Nothing in this document, however, supersedes

applicable laws and regulations unless a specific exemption has been obtained.

3. REQUIREMENTS

3.1 General. The requirements for acquiring the product described herein shall consist of this

document and MIL-PRF-22684.

3.2 Interface and physical dimensions. Resistors shall meet the interface and physical dimensions

specified on figure 1, as applicable.

3.3 Power rating. The power rating shall be 2 watts based on full load operation at an ambient

temperature of 70 C.

3.4 Voltage rating. The maximum continuous working voltage shall not exceed 500 volts.

3.5 Resistance values and resistance tolerances. The minimum and maximum standard resistance

values and associated resistance tolerances shall be as listed in table I.

3.6 Terminal type. The terminal type available shall be in accordance with MIL-PRF-22684 and table I.

3.7 Thermal shock. Resistors shall be tested as specified in MIL-PRF-22684 except 150 C +3 C, -0 C

shall be used instead of 85 C +3 C, -0 C.
