MIL-PRF-22/4D
TABLE I. Style RP11.
Nominal total
Type designator
Maximum current
PIN 1/
resistance
(reference only) 1/
(amperes) 2/
(ohms)
2.0
M22/04-0001---
RP11---2R0KK
2.50
2.5
M22/04-0002---
RP11---2R5KK
2.24
3.0
M22/04-0003---
RP11---3R0KK
2.04
5.0
M22/04-0004---
RP11---5R0KK
1.58
6.0
M22/04-0005---
RP11---6R0KK
1.44
8.0
M22/04-0006---
RP11---6R0KK
1.25
10
M22/04-0007---
RP11---100KK
1.12
15
M22/04-0008---
RP11---150KK
0.91
25
M22/04-0009---
RP11---250KK
0.71
35
M22/04-0010---
RP11---350KK
0.60
50
M22/04-0011---
RP11---500KK
0.50
75
M22/04-0012---
RP11---750KK
0.41
100
M22/04-0013---
RP11---101KK
0.35
150
M22/04-0014---
RP11---151KK
0.29
200
M22/04-0015---
RP11---201KK
0.25
250
M22/04-0016---
RP11---251KK
0.22
350
M22/04-0017---
RP11---351KK
0.19
500
M22/04-0018---
RP11---501KK
0.16
750
M22/04-0019---
RP11---751KK
0.13
1,000
M22/04-0020---
RP11---102KK
0.11
1,500
M22/04-0021---
RP11---152KK
0.09
2,500
M22/04-0022---
RP11---252KK
0.07
3,500
M22/04-0023---
RP11---352KK
0.06
5,000
M22/04-0024---
RP11---502KK
0.05
1/
The complete type designation and part number include symbols
indicting electrical off position from table II, style of shaft and type of
(see 1.2 for example of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
Electrical off position at end of rotation of control knob in a
2
counterclockwise direction.
Electrical off position at end of rotation of control knob in a
3
clockwise direction.
4
