MIL-PRF-22/3D
4. VERIFICATION
4.1 Sampling and inspection. Sampling for delivery shall be in accordance with MIL-PRF-22.
TABLE I. Style RP10.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance
(amperes) 2/
(ohms)
M22/03-0025---
RP10---1R0KK
1.0
5.00
M22/03-0001---
RP10---2R0KK
2.0
3.54
M22/03-0002---
RP10---2R5KK
2.5
3.16
M22/03-0003---
RP10---3R0KK
3.0
2.89
M22/03-0004---
RP10---5R0KK
5.0
2.24
M22/03-0005---
RP10---6R0KK
6.0
2.04
M22/03-0006---
RP10---8R0KK
8.0
1.77
M22/03-0007---
RP10---100KK
10
1.58
M22/03-0008---
RP10---150KK
15
1.29
M22/03-0009---
RP10---250KK
25
1.00
M22/03-0010---
RP10---350KK
35
0.85
M22/03-0011---
RP10---500KK
50
0.71
M22/03-0012---
RP10---750KK
75
0.58
M22/03-0013---
RP10---101KK
100
0.50
M22/03-0014---
RP10---151KK
150
0.41
M22/03-0015---
RP10---201KK
200
0.35
M22/03-0016---
RP10---251KK
250
0.32
M22/03-0017---
RP10---351KK
350
0.27
M22/03-0018---
RP10---501KK
500
0.22
M22/03-0019---
RP10---751KK
750
0.18
M22/03-0020---
RP10---102KK
1,000
0.16
M22/03-0021---
RP10---152KK
1,500
0.13
M22/03-0022---
RP10---252KK
2,500
0.10
M22/03-0023---
RP10---352KK
3,500
0.08
M22/03-0024---
RP10---502KK
5,000
0.07
1/
The complete type designation and part number include symbols
indicting electrical off position from table II, style of shaft and type of
(see 1.2 for example of part number.)
2/
Not to be exceeded on any portion of the winding.
