MIL-PRF-22/14D
TABLE I. Style RP55.
Nominal total
Maximum current
PIN 1/
Type designator 1/
(amperes) 2/
resistance (ohms)
M22/14-0001---
RP55---2R0KK
2.0
22.36
M22/14-0002---
RP55---2R5KK
2.5
20.00
M22/14-0003---
RP55---3R0KK
3.0
18.26
M22/14-0004---
RP55---4R0KK
4.0
15.81
M22/14-0005---
RP55---5R0KK
5.0
14.14
M22/14-0006---
RP55---7R5KK
7.5
11.55
M22/14-0007---
RP55---100KK
10
10.00
M22/14-0008---
RP55---120KK
12
9.13
M22/14-0009---
RP55---150KK
15
8.16
M22/14-0010---
RP55---250KK
25
6.32
M22/14-0011---
RP55---350KK
35
5.35
M22/14-0012---
RP55---500KK
50
4.47
M22/14-0013---
RP55---750KK
75
3.65
M22/14-0014---
RP55---101KK
100
3.16
M22/14-0015---
RP55---151KK
150
2.58
M22/14-0016---
RP55---201KK
200
2.24
M22/14-0017---
RP55---251KK
250
2.00
M22/14-0018---
RP55---351KK
350
1.69
M22/14-0019---
RP55---501KK
500
1.41
M22/14-0020---
RP55---751KK
750
1.15
M22/14-0021---
RP55---102KK
1,000
1.00
M22/14-0022---
RP55---152KK
1,500
0.82
M22/14-0023---
RP55---252KK
2,500
0.63
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
0.375 inch diameter shaft
Symbol
Style of shaft
2 hole mounting
F
Flatted
X
4
