MIL-PRF-22/1D
TABLE I. Style RP06.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance (ohms)
(amperes) 2/
M22/01-0001---
RP06---1R0KK
1.0
3.53
M22/01-0002---
RP06---2R0KK
2.0
2.50
M22/01-0003---
RP06---2R5KK
2.5
2.23
M22/01-0004---
RP06---3R0KK
3.0
2.04
M22/01-0005---
RP06---5R0KK
5.0
1.58
M22/01-0006---
RP06---6R0KK
6.0
1.44
M22/01-0007---
RP06---8R0KK
8.0
1.25
M22/01-0008---
RP06---100KK
10
1.12
M22/01-0009---
RP06---150KK
15
0.91
M22/01-0010---
RP06---250KK
25
0.71
M22/01-0011---
RP06---350KK
35
0.62
M22/01-0012---
RP06---500KK
50
0.50
M22/01-0013---
RP06---750KK
75
0.41
M22/01-0014---
RP06---101KK
100
0.35
M22/01-0015---
RP06---151KK
150
0.29
M22/01-0016---
RP06---201KK
200
0.25
M22/01-0017---
RP06---251KK
250
0.22
M22/01-0018---
RP06---351KK
350
0.19
M22/01-0019---
RP06---501KK
500
0.16
M22/01-0020---
RP06---751KK
750
0.13
M22/01-0021---
RP06---102KK
1,000
0.11
M22/01-0022---
RP06---152KK
1,500
0.091
M22/01-0023---
RP06---252KK
2,500
0.071
M22/01-0024---
RP06---352KK
3,500
0.060
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
.125 inch diameter shaft
Symbol
Style of shaft
Standard bushing
Locking bushing
S
Slotted
X
U
Slotted
X
4
