MIL-PRF-18546G
TABLE I. Characteristic.
Symbol
Method of
Maximum continuous
winding
operating temperature
+250°C
G
Inductive
+250°C
N
Noninductive
1.2.1.3 Resistance. The nominal resistance value expressed in ohms is identified by a four digit
number; the first three represent significant figures, and the last digit specifies the number of zeros to
follow. Where fractional values of an ohm, and values of less than 100 ohms are required, the letter "R"
is substituted for one of the significant digits to represent the decimal point. When the letter "R" is used,
the succeeding digits become significant. The following are examples of symbols for resistance values:
R050 = 0.05 ohm
1000 =
100 ohms
R100 = 0.10 ohm
1001 = 1,000 ohms
1R00 = 1.00 ohm
1002 = 10,000 ohms
10R0 = 10.0 ohms
Minimum and maximum nominal resistance values are as specified (see 3.1). The standard resistance
values for every decade will follow the sequence demonstrated for the "1 to 10" decade (see table II).
TABLE II. Standard resistance values for the 1 to 10 decade. 1/ 2/
1.00
1.27
1.62
2.05
2.61
3.32
4.22
5.23
6.49
8.00
1.02
1.30
1.65
2.10
2.67
3.40
4.32
5.36
6.65
8.06
1.05
1.33
1.69
2.15
2.74
3.48
4.42
5.49
6.81
8.25
1.07
1.37
1.74
2.21
2.80
3.57
4.53
5.62
6.98
8.45
1.10
1.40
1.78
2.26
2.87
3.65
4.64
5.76
7.00
8.66
1.13
1.43
1.82
2.32
2.94
3.74
4.75
5.90
7.15
8.87
1.15
1.47
1.87
2.37
3.01
3.83
4.87
6.00
7.32
9.09
1.18
1.50
1.91
2.43
3.09
3.92
4.99
6.04
7.50
9.31
1.21
1.54
1.96
2.49
3.16
4.02
5.00
6.19
7.68
9.53
1.24
1.58
2.00
2.55
3.24
4.12
5.11
6.34
7.87
9.76
9.90
1/ Resistors having resistance values not listed herein, or in any other decade, will
be considered as not conforming to the specification.
2/ For assistance in ordering 0.0600, 0.0604, 0.0800, and 0.0806, the procuring
activity shall contact the QPL manufacturer.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.
This section does not include documents cited in other sections of this specification or recommended for
additional information or as examples. While every effort has been made to ensure the completeness of
the list, document users are cautioned that they must meet all specified requirements cited in sections 3
and 4 of this specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issue of these documents are those cited in the solicitation or contract (see 6.2).
2
