MIL-PRF-12934/4D
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
3.2 Interface and physical dimensions. The resistors shall meet the interface and physical dimensions specified in
figure 1.
Inches
mm
Inches
mm
Inches
mm
Inches
mm
Inches
mm
.0006
0.02
.010
0.25
.073
1.85
1.375
34.91
2.031
51.59
.001
0.03
.031
0.79
.093
2.36
1.875
47.63
2.250
57.13
.005
0.13
.062
1.57
.250
6.35
2.000
50.80
Maximum starting and running torque
Maximum
(ounce-inch)
continuous
Power
L
K
Single turn
Per each additional
working
Style
Turns
rating (watts)
(max)
(max)
single cup
single-turn cup
voltage
1/
(volts)
Starting
Running
Starting
Running
1.312
.875
RR2000
Single
250
4.0
1.0
1.0
0.8
0.8
(33.32)
(22.23)
1/
When single turn units are ganged, the first cup will be full wattage rating, the remaining cups will be 75
percent of rated wattage.
NOTES:
1.
Dimensions are in inches.
2.
Metric equivalents are given for general information only.
FIGURE 1. Style RR2000
