INCH-POUND
MIL-PRF-12934/4D
25 August 2009
SUPERSEDING
MIL-PRF-12934/4C
1 February 1999
PERFORMANCE SPECIFICATION
RESISTORS, VARIABLE, WIREWOUND, PRECISION,
STYLE RR2000
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall
consist of this specification sheet and MIL-PRF-12934
1. SCOPE
1.1 Scope. This specification covers the requirements for style RR2000, variable, wirewound, precision resistors.
1.2 Part or Identifying Number (PIN). Variable resistors covered by this specification must be identified by a PIN
which must be in the following form.
Single-section (cup) resistors
RR2000
A
2
A
7
J
103
Resistance
Rotational life
Function conformity
Resistance
Style
Function
Class and
temperature
characteristic
tolerance and
(1.2.6)
and shaft
center tap
(1.2.2)
characteristic
(1.2.4)
resistance
length
(1.2.3)
tolerance
(1.2.1)
characteristic
(1.2.5)
1.2.1 Function and shaft length. The function and shaft length applicable to this specification is identified by a
single symbol in accordance with table I.
TABLE I. Function and shaft length.
Shaft length tolerance
Symbol
Function
+ 0.03125 (.79) 1/
A
0.375 (9.53)
B
0.500 (12.70)
C
0.625 (15.88)
Linear
D
0.750 (19.05)
E
0.875 (22.23)
F
1.000 (25.40)
1/
Metric equivalents are in parentheses.
