A-A-55562/1A
3.2 Working voltage (dc). The working voltage (dc) shall be as specified in table I.
3.3 Breakdown voltage. The breakdown voltage shall be as specified in table I.
3.4 Clamping voltage. The clamping voltage shall be as specified in table I.
3.5 Peak current. The peak current shall be as specified in table I.
3.6 Transient energy. The transient voltage shall be as specified in table I.
3.7 Capacitance. The capacitance shall be as specified in table I.
3.8 Inductance. The inductance shall be as specified in table I.
3.9 Termination finish. The termination finish shall be Nickel barrier with Tin alloy plated finish (Ni/Sn), code letter P.
4. REGULATORY REQUIREMENTS. This section is not applicable to this CID.
5. PRODUCT CONFORMANCE PROVISIONS. Product conformance provisions shall be as specified in A-A-
55562.
6. PACKAGING. Packaging shall be as specified in A-A-55562.
7. NOTES
7.1 PIN. The PIN should be used for Government purposes to buy commercial products to this CID. See section 2
for PIN format example.
7.2 Commercial and Government Entity (CAGE) code. For ordering purposes, inventory control, and submission of
these varistors to DSCC under the Military Parts Control Advisory Group (MPCAG) evaluation program, CAGE code
58536 should be used.
7.3 Source of document.
Commercial Item Description
A-A-55562
-
Resistor, Voltage Sensitive (Varistor, Metal Oxide), Chip.
(Copies of commercial item descriptions are available from the Document Automation and Production Service
(DAPS), Building 4D (DPM-DODSSP), 700 Robbins Avenue, Philadelphia, PA 19111-5094.)
7.4 Ordering data. Ordering data shall be as specified in A-A-55562.
7.5 Commercial products. As part of the market analysis and research effort, this CID was coordinated with the
following manufacturers of commercial products. At the time of CID preparation and coordination, these
manufacturers were known to have commercial products that would meet the requirements of this CID. (NOTE:
This information should not be considered as a list of approved manufacturers or be used to restrict procurement to
only the manufacturers shown.)
MFG's CAGE
MFG's name and address
AVX Corporation
3900 Electronics Dr.
16299
Raleigh, NC 27604-1698
(919) 878-6200
3
