MIL-PRF-914-4 Resistor Network, Fixed, Film, Surface Mount, 20-Pin, Leadless Chip Carrier, Nonestablished Reliability And Established Reliability, Style Rns040This specification covers the detail requirements for RNS040 resistor networks. Resistors covered by this specification are considered a monolithic design or wire bond and die construction. The established reliability \(ER\) and nonestablished reliability \(non-ER\) styles are available in all characteristics and resistance tolerances. Designers are CAUTIONED on using these resistors in pulse applications \(see 6.6\).

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8


MIL-PRF-914/4B
Configuration B
Inches
Millimeters
Inches
Millimeters
Ltr
Ltr
Min
Max
Min
Max
Min
Max
Min
Max
A
.015
.025
0.38
0.63
K
.342
.358
8.69
9.09
B
.015
.025
0.38
0.63
L
.015
.025
0.38
0.63
C
.195
.205
4.95
5.21
M
.045
.055
1.14
1.40
D
.035
.045
0.89
1.14
N
.080
.090
2.03
2.29
E
.045
.055
1.14
1.40
P
.022
.028
0.56
0.71
F
---
.085
---
2.20
Q
.015
---
0.38
---
G
.280
.300
7.11
7.62
R
.003
.010
0.08
0.25
H
.018
.028
0.46
0.71
S
.011
.022
0.28
0.56
J
.342
.358
8.69
9.09
FIGURE 2. Leadless chip carrier - Continued
4
