MIL-PRF-55182/7M
*
3.2.2 Terminal types. Terminal RNC is inactive for new design when specified with characteristics C and E.
Terminal RNR is inactive for new design with when specified with characteristics H, J, and K.
3.3 Power rating. The power rating shall be 0.05 watt (see 6.3).
3.4 Voltage rating. The continuous working voltage shall not exceed 200 volts.
3.5 Resistance. Minimum and maximum resistance values shall be as specified in table I.
TABLE I. Minimum and maximum resistance values.
Minimum resistance
Maximum resistance
Characteristic
Ohms
Characteristic
Megohms
0.796
H
10.0
H
0.796
J
10.0
J
0.796
K
10.0
K
0.1
C
10.0
C
0.1
E
10.0
E
3.6 Voltage coefficient (applicable to resistors of 1,000 ohms and above). The voltage coefficient shall not exceed
±0.005 percent per volt.
3.7 Mechanical shear. The mechanical shear test is applicable to this specification.
3.8 Marking. Due to size limitations this style resistor shall be marked with the following minimum information:
226K
-
Date code, characteristic.
49R9
-
Coded resistance value.
FMCJ
-
Tolerance, product level, lead material, JAN marking.
*
-
Manufacturer's code (see qualified products list for manufacturer's code symbols).
4. VERIFICATION
4.1 Verification. Verification shall be in accordance with MIL-PRF-55182.
5. PACKAGING
5.1 Packaging requirements. For acquisition purposes, the packaging requirements shall be as specified in the
contract or order. When actual packaging of material is to be performed by DoD personnel, these personnel need to
contact the responsible packaging activity to ascertain requisite packaging requirements. Packaging requirements
are maintained by the Inventory Control Point's packaging activity within the Military Department or Defense Agency,
or within the Military Department's System Command. Packaging data retrieval is available from the managing
Military Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the
responsible packaging activity.
6. NOTES
(This section contains information of a general or explanatory nature which may be helpful, but is not mandatory.)
6.1 Notes. The notes specified in MIL-PRF-55182 are applicable to this specification.
3
