MIL-PRF-55182/6P
*
3.2 Interface and physical dimensions. Resistors shall meet the interface and physical dimensions specified on
figure 1.
*
3.2.1 Characteristic. Style RN*70 1/ is available in characteristic C, characteristic E, characteristic H, characteristic
J, and characteristic K.
3.2.2 Terminal types. Terminal RNC is inactive for new design when specified with characteristics C and E.
Terminal RNR is inactive for new design with when specified with characteristics H, J, and K.
3.3 Power rating. The power rating shall be 0.50 watt (see 6.3).
3.4 Voltage rating. The continuous working voltage shall not exceed 350 volts.
3.5 Resistance. Minimum and maximum resistance values shall be as specified in table I.
TABLE I. Minimum and maximum resistance values.
Minimum resistance
Maximum resistance
Characteristic
Ohms
Characteristic
Megohms
15.0
H
1.0
H 1/
15.0
J
1.0
J 1/
15.0
K
1.0
K 1/
7.5
C
20.0
C
7.5
E
20.0
E
1/ For resistance tolerance D and resistance tolerance F only.
For resistance tolerance B, the minimum resistance value shall
be 10.0 ohms.
3.6 Voltage coefficient (applicable to resistors of 1,000 ohms and above). The voltage coefficient shall not exceed
±0.005 percent per volt.
4. VERIFICATION
4.1 Verification. Verification shall be in accordance with MIL-PRF-55182.
5. PACKAGING
5.1 Packaging requirements. For acquisition purposes, the packaging requirements shall be as specified in the
contract or order. When actual packaging of material is to be performed by DoD personnel, these personnel need to
contact the responsible packaging activity to ascertain requisite packaging requirements. Packaging requirements
are maintained by the Inventory Control Point's packaging activity within the Military Department or Defense Agency,
or within the Military Department's System Command. Packaging data retrieval is available from the managing
Military Department's or Defense Agency's automated packaging files, CD-ROM products, or by contacting the
responsible packaging activity.
___________
*
1/ Third letter is variable, dependent upon lead material or capability.
3
