MIL-PRF-39023/9B
1.2.7 Output smoothness characteristic. The output smoothness characteristic applicable to this specification are
symbols A to E, inclusive.
1.2.8 Resistance. The nominal total resistance values and maximum end voltage applicable to this specification
will be in accordance with table I.
TABLE I. Nominal total resistance values and maximum end voltage.
Nominal total
Maximum end voltage
resistance values
(percent of total applied voltage)
Ohms
Percent
100
4.0
200
3.0
500
3.0
1,000
2.4
2,000
2.2
5,000
2.1
10,000
2.1
50,000
2.1
0.10 Megohm
2.1
0.20 Megohm
2.1
0.50 Megohm
2.1
1.00 Megohm
2.1
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification. This
section does not include documents cited in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2. .2.1 Specifications, standards, and handbooks. The following specifications, standards, and handbooks form a
part of this document to the extent specified herein. Unless otherwise specified, the issues of these documents are
those cited in the solicitation (see 6.2).
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-PRF-39023 - Resistors, Variable, Nonwirewound, Precision, General Specification for.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or https://assist.daps.dla.mil
or from the Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-5094).
2.3 Order of precedence. In the event of a conflict between the text of this document and the references cited
herein (except for related specification sheets), the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this document and
2
