MIL-PRF-39005/3F
2.2.1 Specifications, standards, and handbooks. The following specifications, standards, and
*
handbooks form a part of this document to the extent specified herein. Unless otherwise specified, the
issues of these documents are those cited in the solicitation or contract.
DEPARTMENT OF DEFENSE SPECIFICATION
MIL-PRF-39005 - Resistors, Fixed, Wire-Wound (Accurate), Nonestablished Reliability and
Established Reliability, General Specification for.
(Copies of these documents are available online at https://assist.daps.dla.mil/quicksearch/ or from the
*
Standardization Document Order Desk, 700 Robbins Avenue, Building 4D, Philadelphia, PA 19111-
5094.)
2.3 Order of precedence. Unless otherwise noted herein or in the event of a conflict between the text
*
of this document and the references cited herein (except for related specification sheets), the text of this
document takes precedence. Nothing in this document, however, supersedes applicable laws and
regulations unless a specific exemption has been obtained.
3. REQUIREMENTS
3.1 General. The requirements for acquiring the product described herein shall consist of this
document and MIL-PRF-39005.
3.2 Interface and physical dimensions. Resistors shall meet the interface and physical dimensions
specified on figure 1.
3.3 Minimum resistance value and applicable tolerance. Minimum resistance value shall be 0.1 ohm
for tolerance F (±1.0 percent). For tolerances B, A, Q, T (±.10, ±.05, ±.02, and ±.01 percent,
respectively), the minimum resistance value shall be 0.499 ohms.
3.4 Maximum resistance value. Maximum resistance values and applicable wire sizes shall be as
follows:
Nominal wire size
Absolute
Maximum resistance
(inches) diameter
diameter
value
(megohms)
.001
.0009
.255
.0009
.00081
.383
.0008
.00072
.562
3.5 Power rating. Power rating shall be 0.25 watt.
3.6 Maximum voltage. Maximum voltage shall be 300 volts direct current or peak.
3.7 Maximum weight. The maximum weight shall be 2.5 grams.
4. VERIFICATION
4.1 Verification. Verification shall be in accordance with MIL-PRF-39005.
