MIL-PRF-39002/1G
TABLE I. Style RK09 resistor - Continued.
Shaft length
Dash number
Nominal
Type
Rated ac and
Nominal total
(slotted shaft
resolution 2/
designation
dc working
Terminal
resistance
style) in inches
Locking
Standard
1/
(percent)
voltage (volts)
value (ohms)
±.031
bushing
bushing
RK09SKCS502
5,000
.17
86
0182
RK09SKCS752
7,500
.21
104
0183
RK09SKCS103
10,000
.15
122
0184
RK09SKCS153
15,000
.13
150
0185
3/
RK09SKCS203
20,000
.12
173
0186
2.500
S
NA
RK09SKCS253
25,000
.114
194
0187
RK09SKCS353
35,000
.102
229
0188
RK09SKCS503
50,000
.080
272
0189
4/
RK09SKCS753
75,000
.060
290
0202
RK09SKCS104
100,000
4/
.045
300
0203
1/ For reference purposes only.
2/ Percent of resolution = 1/N x 100. N = number of turns.
3/ Maximum value based on use of wire having no less than .001 inch (0.13 mm) nominal diameter.
NOTE: For Navy use, resistance values shall be based on the use of wire having no maximum less than
0.001 inch (0.03 mm) wire diameter.
4/
Valued based on use of wire having no less than 0.0006 inch (0.15 mm) nominal diameter.
NOTE: For Army and Air Force use, resistance values shall be based on the of wire having no less than
0.0006 inch (0.15 mm) wire diameter.
3.16 Marking. Due to size limitations, marking of the schematic diagram is optional.
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-39002.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military Department's
or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible packaging
activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Notes. The notes specified in MIL-PRF-39002 are applicable to this specification.
6.2 Acquisition requirements. Acquisition documents must specify the following:
a.
Title, number, and date of this date of this specification, the applicable associated specification, and the
complete PIN.
b.
Unless otherwise specified (see 2.1), the versions of the individual documents referenced will be those in
effect on the date of release of the solicitation.
