MIL-PRF-22097/6G
3.3 Power rating. The power rating shall be .25 watt for characteristic C and characteristic F.
3.4 Terminals. Characteristic C and characteristic F are available in P-type only.
3.5 Nominal resistance value and maximum rated ac or dc working voltage. Nominal resistance values and
maximum rated ac or dc working voltages shall be as specified in table I.
TABLE I. Nominal resistance value and maximum rated ac or dc working voltage.
Maximum rated ac or dc
Maximum rated ac or dc
Nominal
working voltage per
Nominal
working voltage per
resistance value
characteristic C and
resistance value
characteristic C and
(Ohms)
characteristic F
(Ohms)
characteristic F
(Volts)
(Volts)
10
1.58
10,000
50.0
20
2.23
20,000
70.7
3.54
79.0
50
25,000
5.00
111
100
50,000
7.07
158
200
100,000
11.1
200
500
200,000
15.8
200
1,000
250,000
22.3
200
2,000
500,000
5,000
35.4
1,000,000
200
O
3.6 Actual effective electrical travel. Actual effective electrical travel shall be 215 minimum.
3.7 Torque.
3.7.1 Operating. The operating torque shall be a maximum of 2 ounce-inches.
3.7.2 Stop. The stop shall withstand a force of 4 ounce-inches when this amount of torque is applied through the
operating shaft to the stop.
3.8 Pure tin. The use of pure tin, as an underplate or final finish, is prohibited both internally and externally. Tin
content of resistor components and solder shall not exceed 97 percent, by mass. Tin shall be alloyed with a
minimum of 3 percent lead, by mass (see 6.4).
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-22097, and as
specified herein.
4.2 Dielectric withstanding voltage. The magnitude of test voltage shall be 600 volts at atmospheric pressure, and
250 volts at reduced barometric pressure.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military Department's
or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible packaging
activity.
3
