MIL-PRF-22097/5E
TABLE I. Nominal resistance value and maximum rated ac or dc working voltage.
Maximum rated ac or dc
Maximum rated ac or dc
Nominal
Nominal
working voltage per
working voltage per
resistance value
resistance value
characteristic C and
characteristic C and
(Ohms)
(Ohms)
characteristic F
characteristic F
(Volts)
(Volts)
10
1.58
10,000
50.0
20
2.23
20,000
70.7
50
3.54
25,000
79.0
100
5.00
50,000
111
200
7.07
100,000
158
500
11.1
200,000
200
1,000
15.8
250,000
200
2,000
22.3
500,000
200
5,000
35.4
1,000,000
200
4. VERIFICATION
4.1 Sampling and inspection. Sampling and inspection shall be in accordance with MIL-PRF-22097, and as
specified herein.
4.2 Dielectric withstanding voltage. The magnitude of test voltage shall be 600 volts at atmospheric pressure, and
250 volts at reduced barometric pressure.
5. PACKAGING
5.1 Packaging. For acquisition purposes, the packaging requirements shall be as specified in the contract or order
(see 6.2). When packaging of materiel is to be performed by DoD or in-house contractor personnel, these personnel
need to contact the responsible packaging activity to ascertain packaging requirements. Packaging requirements are
maintained by the Inventory Control Point's packaging activity within the Military Service or Defense Agency, or within
the military services system commands. Packaging data retrieval is available from the managing Military Department's
or Defense Agency's automated packaging files, CD-ROM products, or by contacting the responsible packaging
activity.
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Intended use. The notes specified in MIL-PRF-22097 are applicable to this specification.
6.2 Acquisition requirements. Acquisition documents must specify the following:
a.
Title, number, and date of this date of this specification, the applicable associated specification, and the
complete PIN.
b.
Unless otherwise specified (see 2.1), the versions of the individual documents referenced will be those in
effect on the date of release of the solicitation.
c.
Packaging requirements (see 5.1).
d.
Allowable substitution.
6.3 Weight. The maximum weight is .021 ounces (0.6 grams).
4
