MIL-PRF-22/8D
TABLE I. Style RP25.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance (ohms)
(amperes) 2/
M22/08-0001---
RP25---2R0KK
2.0
7.07
M22/08-0002---
RP25---2R5KK
2.5
6.32
M22/08-0003---
RP25---3R0KK
3.0
5.77
M22/08-0004---
RP25---4R0KK
4.0
5.00
M22/08-0005---
RP25---5R0KK
5.0
4.47
M22/08-0006---
RP25---6R0KK
6.0
4.08
M22/08-0007---
RP25---8R0KK
8.0
3.53
M22/08-0008---
RP25---100KK
10
3.16
M22/08-0009---
RP25---120KK
12
2.89
M22/08-0010---
RP25---150KK
15
2.58
M22/08-0011---
RP25---250KK
25
2.00
M22/08-0012---
RP25---350KK
35
1.69
M22/08-0013---
RP25---500KK
50
1.41
M22/08-0014---
RP25---750KK
75
1.15
M22/08-0015---
RP25---101KK
100
1.00
M22/08-0016---
RP25---151KK
150
0.82
M22/08-0017---
RP25---201KK
200
0.71
M22/08-0018---
RP25---251KK
250
0.63
M22/08-0019---
RP25---351KK
350
0.54
M22/08-0020---
RP25---501KK
500
0.45
M22/08-0021---
RP25---751KK
750
0.37
M22/08-0022---
RP25---102KK
1,000
0.32
M22/08-0023---
RP25---152KK
1,500
0.26
M22/08-0024---
RP25---252KK
2,500
0.20
M22/08-0025---
RP25---352KK
3,500
0.17
M22/08-0026---
RP25---502KK
5,000
0.14
M22/08-0027---
RP25---802KK
8,000
0.11
M22/08-0028---
RP25---103KK
10,000
0.10
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
.25 inch diameter shaft
Symbol
Style of shaft
Standard bushing
Locking bushing
F
Flatted
X
S
Slotted
X
T
Flatted
X
U
Slotted
X
4
