MIL-PRF-22/6E
TABLE I. Style RP16.
Type designator
Nominal total
Maximum current
PIN 1/
(reference only) 1/
resistance (ohms)
(amperes) 2/
RP16---1R0KK
1.0
5.00
M22/06-0001---
RP16---2R0KK
2.0
3.54
M22/06-0002---
RP16---2R5KK
2.5
3.16
M22/06-0003---
RP16---3R0KK
3.0
2.89
M22/06-0004---
RP16---4R0KK
4.0
2.50
M22/06-0005---
RP16---5R0KK
5.0
2.24
M22/06-0006---
RP16---6R0KK
6.0
2.04
M22/06-0007---
RP16---8R0KK
8.0
1.77
M22/06-0008---
RP16---100KK
10
1.58
M22/06-0009---
RP16---120KK
12
1.44
M22/06-0010---
RP16---150KK
15
1.29
M22/06-0011---
RP16---250KK
25
1.00
M22/06-0012---
RP16---350KK
35
0.85
M22/06-0013---
RP16---500KK
50
0.71
M22/06-0014---
RP16---750KK
75
0.58
M22/06-0015---
RP16---101KK
100
0.50
M22/06-0016---
RP16---151KK
150
0.41
M22/06-0017---
RP16---201KK
200
0.35
M22/06-0018---
RP16---251KK
250
0.32
M22/06-0019---
RP16---351KK
350
0.27
M22/06-0020---
RP16---501KK
500
0.22
M22/06-0021---
RP16---751KK
750
0.18
M22/06-0022---
RP16---102KK
1,000
0.16
M22/06-0023---
RP16---152KK
1,500
0.13
M22/06-0024---
RP16---252KK
2,500
0.10
M22/06-0025---
RP16---352KK
3,500
0.08
M22/06-0026---
RP16---502KK
5,000
0.07
M22/06-0027---
RP16---802KK
8,000
0.06
M22/06-0028---
RP16---103KK
10,000
0.05
M22/06-0029---
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
.25 inch diameter shaft
Symbol
Style of shaft
Standard bushing
Locking bushing
F
Flatted
X
S
Slotted
X
T
Flatted
X
U
Slotted
X
4
