MIL-PRF-22/5D
TABLE I. Style RP15.
Nominal total
Maximum current
PIN 1/
Type designator 1/
resistance
(amperes) 2/
(ohms)
M22/05-0001---
RP15---1R0KK
1.0
7.07
M22/05-0002---
RP15---2R0KK
2.0
5.00
M22/05-0003---
RP15---2R5KK
2.5
4.47
M22/05-0004---
RP15---3R0KK
3.0
4.08
M22/05-0005---
RP15---4R0KK
4.0
3.54
M22/05-0006---
RP15---5R0KK
5.0
3.16
M22/05-0007---
RP15---6R0KK
6.0
2.89
M22/05-0008---
RP15---8R0KK
8.0
2.50
M22/05-0009---
RP15---100KK
10
2.24
M22/05-0010---
RP15---120KK
12
2.04
M22/05-0011---
RP15---150KK
15
1.83
M22/05-0012---
RP15---250KK
25
1.41
M22/05-0013---
RP15---350KK
35
1.19
M22/05-0014---
RP15---500KK
50
1.00
M22/05-0015---
RP15---750KK
75
0.82
M22/05-0016---
RP15---101KK
100
0.71
M22/05-0017---
RP15---151KK
150
0.58
M22/05-0018---
RP15---201KK
200
0.50
M22/05-0019---
RP15---251KK
250
0.45
M22/05-0020---
RP15---351KK
350
0.38
M22/05-0021---
RP15---501KK
500
0.32
M22/05-0022---
RP15---751KK
750
0.26
M22/05-0023---
RP15---102KK
1,000
0.22
M22/05-0024---
RP15---152KK
1,500
0.18
M22/05-0025---
RP15---252KK
2,500
0.14
M22/05-0026---
RP15---352KK
3,500
0.12
M22/05-0027---
RP15---502KK
5,000
0.10
M22/05-0028---
RP15---802KK
8,000
0.08
M22/05-0029---
RP15---103KK
10,000
0.07
1/
The complete type designation and part number include symbols indicting
electrical off position from table II, style of shaft and type of mounting from
of part number.)
2/
Not to be exceeded on any portion of the winding.
TABLE II. Electrical off position.
Symbol
Electrical off position
1
No electrical off position.
2
Electrical off position at end of rotation of control knob in a counterclockwise direction.
3
Electrical off position at end of rotation of control knob in a clockwise direction.
TABLE III. Style of shaft and type of mounting.
Symbol
Style of shaft
.25 inch diameter shaft
Standard bushing
Locking bushing
F
Flatted
X
S
Slotted
X
T
Flatted
X
U
Slotted
X
4
